| Model | Model | F200 Series-20W | 30W(High-Speed Custom Model) | 50W | 70W | 100W |
| Application Industry | Key Applications | Electronics, Automotive Parts, Metal Hardware, Wires/Cables, Food
Packaging, Pharmaceuticals, Cosmetics |
| Applicable Materials | Compatible Materials | Metals & Non-Metals (PVC, PE, PC, CPP, PA, PPO extrusion materials) |
| Product Features | Laser Type | Fiber Laser |
| Laser Power | ≥20W | ≥30W | ≥50W | ≥70W | ≥100W |
| Laser | fiber laser generator |
| Wavelength | 1064nm |
| Max Marking Speed | ≤12,000mm/s | ≤12000mm/s | ≤12000mm/s | ≤15000mm/s | ≤12000mm/s |
| Control Mainboard | Industrial-grade Highly Integrated All-in-One Mainboard |
| Operating System | Linux |
| Cooling System | Ambient Air Cooling (No Compressed Air Required) |
| Marking System | Dedicated Laser Coding System |
| Operation Interface | 10.1" Touchscreen | 10" Touchscreen |
| Data Interfaces | USB 2.0 / SD Card / Communication Port |
| Data Protection | Power-failure proof (prevents data loss) |
| Lens Adjustment | 90° rotatable scanning head |
| Power Requirements | AC220V, 50-60Hz |
| Machine Power | 500W | 700w | 700w | 700w | 1200W |
| Protection Rating | IP54 (Dust & Splash Resistant) |
| Machine Weight | 70kg |
| Dimensions (L×W×H) | 650×520×1480mm |
| Pollution Level | The marking itself does not produce any chemical substances. |
| Environmental Adaptability | Storage Environment Temperature | ’-10℃ to -45℃ (non-freezing) |
| Operating Environment Temperature |
| Storage Environment Humidity | 10% to 85% (no condensation) |
| Operating Environment Humidity |
| Lens Configuration | Marking Range | 110 * 110 mm |
| Marking Line Type | Dot matrix, Vector |
| Minimum Line Width | 0.01 mm |
| Repeat Positioning Accuracy | 0.01 mm |
| Positioning Method | Red light positioning, Red light focusing |
| Number of Marking Characters | Editable within the marking range |
| Production Line Speed | 0-180 m/min (depending on product material and marking content) |
| Marking Type | Supported Font Types | Single-line font / Double-line font / Dot matrix font |
| Graphic File Format | PLT format vector file input/output |
| Graphic Elements | Points, Lines, Arcs, Text, Rectangles, Circles |
| Variable Text | Serial numbers, Time, Date, Counters, Shifts |
| Online Editing | Supports online editing of marking information without stopping the
machine. |
| Software Customization | Software can be customized and developed according to the various
control requirements of the user's production line. |
| Technical Documentation | Provides a simple operation manual for the equipment, detailed
software instructions (on CD), and relevant certificates of
compliance. |
